Richmet Steel Industries is a leading Pipes & Tubes Manufacturer in India. We offer a wide range of pipes and tubes such as seamless, ERW, and welded types in various shapes, sizes, and specifications to meet diverse industrial requirements. These products are widely used in industries like oil and gas, petrochemical, construction, and power generation for fluid transportation, structural applications, and mechanical systems.
Richmet Steel Industries is a leading Pipes & Tubes Supplier in India, offering high-quality seamless, ERW, and welded pipes and tubes for various industrial applications. Manufactured with premium materials, our products ensure durability, strength, and reliable performance, and can be customized to meet specific client requirements at competitive prices.
| Pipes & Tubes | Specification |
|---|---|
| Size | 1/2″ NB to 24″ NB |
| Types | Seamless / ERW / Welded / Fabricated |
| Length | Single Random, Double Random, Cut Length |
| Schedule | SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH60, SCH80, XS, SCH100, SCH120, SCH140, SCH160, XXS |
| Standards | ASTM A106, ASTM A53, ASTM A312 / ASME SA106, SA53, SA312 |
| Material | Carbon Steel, Stainless Steel, Alloy Steel |
Get A Quote Now!
| DIMENSION | 10 SWG (3.2 MM) |
12 SWG (2.6 MM) |
14 SWG (2.1 MM) |
16 SWG (1.65 MM) |
18 SWG (1.2 MM) |
19 SWG (1.0 MM) |
|
|---|---|---|---|---|---|---|---|
| Size | OD | Weight/MTR | Weight/MTR | Weight/MTR | Weight/MTR | Weight/MTR | Weight/MTR |
| 1/2" | 12.7 | 0.754 | 0.651 | 0.552 | 0.452 | 0.342 | 0.290 |
| 5/8" | 15.875 | 1.006 | 0.856 | 0.718 | 0.582 | 0.437 | 0.369 |
| 3/4" | 19.05 | 1.258 | 1.061 | 0.883 | 0.712 | 0.531 | 0.448 |
| 1" | 25.4 | 1.762 | 1.470 | 1.214 | 0.972 | 0.720 | 0.605 |
| 1 1/4" | 31.75 | 2.266 | 1.880 | 1.544 | 1.232 | 0.909 | 0.763 |
| 1 1/2" | 38.1 | 2.770 | 2.289 | 1.875 | 1.492 | 1.098 | 0.920 |
| 2" | 50.8 | 3.778 | 3.108 | 2.537 | 2.012 | 1.476 | 1.235 |
| 2 1/2" | 63.5 | 4.786 | 3.928 | 3.198 | 2.531 | 1.854 | 1.550 |
| 3" | 76.2 | 5.794 | 4.747 | 3.860 | 3.051 | 2.232 | 1.865 |
| 3 1/2" | 88.9 | 6.802 | 5.566 | 4.521 | 3.571 | 2.610 | 2.180 |
| 4" | 101.6 | 7.810 | 6.385 | 5.183 | 4.091 | 2.988 | 2.495 |
| Specification | Allowable Outside Diameter Variation (mm) | Allowable Wall Thickness Variation | Exact Length Tolerance (mm) | Testing | |||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Diameter | Over | Under | % Over | % Under | Over | Under | |||||||||||||||||||||
|
ASTM-A213 Seamless Boiler Superheater and Heat Exchanger Tubes |
|
+20 , +22 (others) |
-0 | 3.175 to 4.76 | 0 | Flattening Test Tension Test Flare Test Hardness Test 100% Hydrostatic test Refer to ASTM A-450 | |||||||||||||||||||||
|
ASTM-A249 Welded Boiler Superheater, Heat Exchanger and Condenser Tubes |
|
+10 | -10 | 3.175 to 4.762 | 0 | Tension Test Flattening Test Flange Test Reverse Bend Test Hardness Test 100% Hydrostatic Test Refer to ASTM A-450 |
|||||||||||||||||||||
|
ASTM-A269 Seamless & Welded Tubing for General Service |
|
+10 | -10 | 3.2 to 4.8 | 0 | Flare Test (Seamless Only) Flange Test (Welded Only) Hardness Test Reverse Flattening Test (Welded only) 100% Hydrostatic Test Refer to ASTM-A269 |
|||||||||||||||||||||
| ASTM-A270 Seamless & Welded Sanitary Tubing |
|
+10 | -10 | 3.2 to 4.8 | 0 | Tension Test Flattening Test 100% Hydrostatic Test Refer to ASTM A-530 |
|||||||||||||||||||||
|
ASTM-A312 Seamless & Welded pipe |
|
12.5% under nominal | 6.4 | 0 | Tension Test Flattening Test 100% Hydrostatic Test Refer to ASTM A-530 |
||||||||||||||||||||||
| ASTM A-358 Welded pipe |
|
-0.3 | 6.0 | Refer to ASTM A-530 | |||||||||||||||||||||||
| Nominal Bore | Outside Diameter mm |
Sch-5S | Sch-10S | Sch-40S | Sch-80S | Sch-160S | Sch-XXS | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | INCH | Wt mm | Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | Wt mm | Weight (Kg/mt) | |
| 3 | 1/8 | 10.3 | 1.24 | 0.276 | 1.24 | 0.28 | 1.73 | 0.37 | 2.41 | 0.47 | - | - | - | - |
| 6 | 1/4 | 13.7 | 1.24 | 0.390 | 1.65 | 0.49 | 2.24 | 0.631 | 3.02 | 0.80 | - | - | - | - |
| 10 | 3/8 | 17.1 | 1.24 | 0.490 | 1.65 | 0.63 | 2.31 | 0.845 | 3.20 | 1.10 | - | - | - | - |
| 15 | 1/2 | 21.3 | 1.65 | 0.800 | 2.11 | 1.00 | 2.77 | 1.27 | 3.75 | 1.62 | 4.75 | 1.94 | 7.47 | 2.55 |
| 20 | 3/4 | 26.7 | 1.65 | 1.03 | 2.11 | 1.28 | 2.87 | 1.68 | 3.91 | 2.20 | 5.54 | 2.89 | 7.82 | 3.63 |
| 25 | 1 | 33.4 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.24 | 6.35 | 4.24 | 9.09 | 5.45 |
| 32 | 1 1/4 | 42.2 | 1.65 | 1.65 | 2.77 | 2.70 | 3.56 | 3.38 | 4.85 | 4.47 | 6.35 | 5.61 | 9.70 | 7.77 |
| 40 | 1 1/2 | 48.3 | 1.65 | 1.91 | 2.77 | 3.11 | 3.68 | 4.05 | 5.08 | 5.41 | 7.14 | 7.25 | 10.16 | 9.54 |
| 50 | 2 | 60.3 | 1.65 | 2.40 | 2.77 | 3.93 | 3.91 | 5.44 | 5.54 | 7.48 | 8.74 | 11.1 | 11.07 | 13.44 |
| 65 | 2 1/2 | 73.0 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.63 | 7.01 | 11.4 | 9.53 | 14.9 | 14.2 | 20.39 |
| 80 | 3 | 88.9 | 2.11 | 4.51 | 3.05 | 6.45 | 5.49 | 11.30 | 7.62 | 15.2 | 11.1 | 21.3 | 15.24 | 27.65 |
| 100 | 4 | 114.3 | 2.11 | 5.84 | 3.05 | 8.36 | 6.02 | 16.07 | 8.56 | 22.3 | 13.49 | 33.54 | 17.12 | 41.03 |
| 125 | 5 | 141.3 | 2.77 | 9.47 | 3.40 | 11.57 | 6.55 | 21.8 | 9.53 | 31.97 | 15.88 | 49.11 | 19.05 | 57.43 |
| 150 | 6 | 168.3 | 2.77 | 11.32 | 3.40 | 13.84 | 7.11 | 28.3 | 10.97 | 42.7 | 18.2 | 67.56 | 21.95 | 79.22 |
| 200 | 8 | 219.1 | 2.77 | 14.79 | 3.76 | 19.96 | 8.18 | 42.6 | 12.7 | 64.6 | 23.0 | 111.2 | 22.23 | 107.8 |
| 250 | 10 | 273.1 | 3.40 | 22.63 | 4.19 | 27.78 | 9.27 | 60.5 | 12.7 | 96.0 | 28.6 | 172.4 | 25.40 | 155.15 |
| 300 | 12 | 323.9 | 3.96 | 31.25 | 4.57 | 36.00 | 9.52 | 73.88 | 12.7 | 132.0 | 33.32 | 238.76 | 25.40 | 186.97 |
| 350 | 14 | 355.6 | 3.96 | 34.36 | 4.78 | 41.3 | 11.13 | 94.59 | 19.05 | 158.08 | 35.71 | 281.70 | - | - |
| 400 | 16 | 406.4 | 4.19 | 41.56 | 4.78 | 47.29 | 12.7 | 123.30 | 21.41 | 203.33 | 40.46 | 365.11 | - | - |
| 450 | 18 | 457.2 | 4.19 | 46.80 | 4.78 | 53.42 | 14.27 | 155.80 | 23.8 | 254.36 | 45.71 | 466.40 | - | - |
| 500 | 20 | 508.0 | 4.78 | 59.25 | 5.54 | 68.71 | 15.09 | 183.42 | 26.19 | 311.2 | 49.99 | 564.68 | - | - |
| 600 | 24 | 609.6 | 5.54 | 82.47 | 6.35 | 94.45 | 17.48 | 255.41 | 30.96 | 442.08 | 59.54 | 808.22 | - | - |
This chart includes weights of standard stainless steel pipes per meter length. Stainless Steel 304 and 316 grades are most commonly used for sanitary and industrial piping.
| Pipe Size (Inch) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2″ | 21.34 | 2.77 | 1.26 |
| 3/4″ | 26.67 | 2.87 | 1.68 |
| 1″ | 33.40 | 3.38 | 2.50 |
| 1.5″ | 48.26 | 3.68 | 4.37 |
| 2″ | 60.33 | 3.91 | 5.85 |
| 3″ | 88.90 | 5.49 | 11.70 |
| 4″ | 114.30 | 6.02 | 17.15 |
Mild Steel (MS) pipes are typically used in construction and fabrication. Below is the MS pipe weight chart based on average thickness and standard sizes.
| Pipe Size (Inch) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2″ | 20 | 2.0 | 0.99 |
| 1″ | 25 | 2.5 | 1.53 |
| 2″ | 50 | 3.0 | 3.51 |
| 3″ | 75 | 3.5 | 6.98 |
| 4″ | 100 | 4.0 | 10.32 |
| 6″ | 150 | 5.0 | 19.48 |
This chart shows the weight of steel pipes based on their schedule and size. These schedules define wall thickness and therefore directly impact weight.
| Pipe Size | Schedule | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1″ | SCH 10 | 2.77 | 1.56 |
| 1″ | SCH 40 | 3.38 | 2.50 |
| 1″ | SCH 80 | 4.55 | 3.24 |
| 2″ | SCH 40 | 3.91 | 5.85 |
| 3″ | SCH 40 | 5.49 | 11.70 |
